| Attributes | Description |
|---|---|
| Interface | 8*XG(S)-PON/GPON Combo port, 8* GE/10GE SFP + 2*100G QSFP28 |
| Exchange Capacity | 720Gbps |
| Forwarding Rate | 535.68Mpps |
| Memory & Flash | DRAM: 2GB; Flash: 8GB |
| Management Port | Console, MGMT |
| PON Standards | Comply with ITU-T G.987/G.988 standard Wavelength: GPON: 1490nm downstream & 1310nm upstream; XSGPON: 1577nm downstream & 1270nm upstream; |
| PON Speeds | GPON: Downstream - 2.5Gbps, Upstream - 1.25Gbps; XGPON: Downstream - 10Gbps, Upstream - 2.5Gbps. XGSPON: Downstream - 10Gbps, Upstream - 10Gbps; |
| PON Distance | GPON supports a maximum distance of 60KM logical distance, 20KM physical distance, and 20KM differential distance; XGPON supports a maximum distance of 100KM logical distance, 40KM physical distance, and 40KM differential distance; |
| PON Split Ratio | PON port 1:256 Maximum split ratio in total: GPON 1:128, XGPON/XGSPON 1:128 Standard OMCI management function; PON module adapts to standard 20PIN SFP+ package module |
| Fan | Modular fans supply * 3 |
| Power | AC: 100~240V 47/63Hz; DC: 36V~75V |
| Power Consumption | ≤120W |
| Weight | 6.5kg |
| Dimensions (W*H*D) | 440mm*44mm*270mm (not including mounting ears) |
| Environment Temperature | Working Temperature: -10°C~55°C Storage Temperature: -40°C~70°C |
| Environment Humidity | Relative Humidity: 5%~95% (non-condensing) |
