| Interface | 1*2.5G+3GE+1VOIP+1USB+WIFI6+XGPON |
| LED | POWER+PON/LOS +INTERNET +LAN+VOIP + WiFi + WPS+USB |
| Button | POWER + RST +WIFI+WPS+LED |
| Flash & Memory | Flash: 128MB NAND; Memory: 512MB DDR4 |
| Power Supply | 12V/2A |
| Power Consumption | ≤ 20W |
| Environment Standard | Operating Temperature: -5°C~45°C Storage Temperature: -20°C~70°C Relative Humidity: 5%~95% (non-condensing) |
| Weight | 0.35KG |
| Size | 190mm*135mm*33mm (L*W*H) |
| Module Type | Class B+, SC/UPC |
| Wavelength | UP 1270nm, Down 1577nm |
| TX Optical Power | 4~9dbm |
| RX Optical Sensitivity | -28dBm |
| Transmission Distance | 0~20km |
| Transmission Rate | XGPON: Upstream 2.5Gbps / Downstream 10Gbps |
| LAN Interface Type | LAN1 - LAN3: RJ45 (10/100/1000Mbps) LAN4: RJ45 (100/1000/25000Mbps) |
| USB | USB 3.0 |
| WIFI | Dual-band WIFI6 AX3000 2×2 MIMO (2.4G & 5G) |
| VOIP | RJ11 |
| Description | Accessories |
| 1*2.5GE+3GE+1VOIP+1USB+WIFI6+XGPON | Power Adapter, RJ45 cable, RJ11 cable |
