The HG8546M GPON ONT is a new terminal-level GPON ONT designed for FTTB, FTTH, and FTTO access applications in ISP FTTH networks. It supports pure data, data + voice, data + voice + Wi-Fi, and other service access types.
The HG8546M ONT supports the standard OMCI interface and delivers high-speed data transfer rates of up to 1.25 Gbps uplink and 2.5Gbps downlink. It fully meets the equipment requirements of ISPs for FTTB, FTTH, and FTTO deployments and integrates seamlessly with our NGBN unified network management system. The HG8546M offers comprehensive functionality to support these needs.
| Model | HG8546M / EG8141A5 |
| Out Port contains | 1GE+3FE+1POT+1USB+WiFi |
| WIFI signal | 2.4GHz wifi |
| Wireless gain | 5dBi |
| USB | 2.0 |
| LAN | 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
| TEL | H248/SIP Voice Protocol |
| PPPOE BRIDGE | Support |
| Firmware | English |
| Dimension/weight | 153mm*125mm*32mm / 176g |
| Fiber port | 1 GPON/EPON interface, single-fiber, Downstream rate 2.5Gbps; Upstream rate 1.25Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Fiber interface | SC/UPC / SC/APC Single mode |
| RX sensitivity | < -28dBm (1490nm) |
| DC power | 12V 1.0A, external AC-DC power adapter |
| Operation | Working temperature: -5℃ - +55℃; Working humidity: 10-90% (non-condensation) |
| Storage | Storage temperature: -30℃ - +60℃; Storage humidity: 10-90% (non-condensation) |
| Description | Accessories Pack |
|---|---|
|
1*xPON + 1*GE RJ45 + 3*FE RJ45 + 1*RJ11 POTS 2*External 5dBi antennas 2.4GHz Wi-Fi 4 |
Power Adapter |
A1: Depends on products, different products have different MOQ.
A2: Yes, we can offer the customization service to you.
A3: Yes, all of our products is without lock, support to another brands too.
A4: We are the manufacturer, we support factory view tour.
A5: Yes, for some models we are able to provide the free samples for your testing purpose.
A6: Yes, according the contract agreement, we are able to apply for the local certificates for you, such as Postel/CE/Rohs/Anatel etc.
