Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
1 / 5
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU
Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU

Fully Certified 2.4&5G Dual Band XPON ONT with Realtek Chipset FTTH 4 RJ45 Ports Dual Band ONU

Send Inquiry

Product Description

EPON/GPON Dual-mode Access
EPON/GPON Dual-mode Access Reduce the Investment of Operators
Compatible with Various OLT
Compatible with Various OLT, Flexible Networking
2.4G+5G Dual-band WiFi
2.4G+5G Dual-band WiFi, High-Speed Connection
Multiple Application Scenarios
Multiple Application Scenarios
Compact & Elegant Design
Compact & Elegant Design
Product Specification Design
Specification
Model Number HG8024X
Interface 1* G/EPON + 4*GE + 2.4G/5.8G WLAN
Ethernet Interface 4* RJ45 10/100/1000BASE-T
PON Interface Interface Type: SC/UPC, CLASS B+
Transmission distance: 0 ~ 20km
Working wavelength: Up 1310nm; Down 1490nm
RX Optical power sensitivity: -27dBm
Transmission rate:
GPON: Up 1.244Gbps; Down 2.488Gbps
EPON: Up 1.244Gbps; Down 1.244Gbps
Wireless Interface type: 4*2T2R External antenna
Antenna gain: 5dBi
Interface maximum rate:
2.4G WLAN: 300Mbps
5.8G WLAN: 866Mbps
Interface working mode:
2.4G WLAN: 802.11 b/g/n
5.8G WLAN: 802.11 a/n/ac
Indicator light POWER/PON/LOS/LAN1/ LAN2/LAN3/LAN4/FXS1/FXS2/2.4G/5G
Power Supply DC 12V/0.5A
Power Adapter Input 100V-240V AC, 50Hz-60Hz
Power Consumption 18W
Working Temperature -20℃ ~ +50℃
Environment Humidity 5% ~ 95% (non-condensing)
Dimensions(L×W×H) 196mm x 125mm x 32mm
Order Info
Description XPON, 4*1000M Base-T, 1*WIFI-5(2.4G&5G 1200M), 12V/1A.
FAQ
Q Can you do OEM?
Yes, we can do OEM products. It is not a problem.
Q How is quality control managed?
Every single optic module is individually tested in our test center, and also tested for compatibility on a variety of different network equipments.
Q Can I get a sample first?
Yes, we can provide samples for you to check the quality.
Q How about the payment terms?
We accept T/T, western union, and secure online orders.
Q What is the lead time?
For usual orders, we keep stock and could ship about 3 days after receiving the payment. For big quantity & special products, please verify the lead time beforehand.
Q How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
