Dual Band XPON ONU WiFi 5 4GE 1POTS 1USB GPON EPON Compatible ONU Router

Product Description

Product Showcase
Product Design
Design Detail 1 Design Detail 2
Design Detail 3 Design Detail 4
Specification
GPON ONU EG8145V5 XPON ONT 4GE+1VOIP+WIFI+2.4G+5G SC/UPC SC/APC FTTH
Dimensions (H x W x D) 30 mm x 173 mm x 120 mm (without external antenna and pads)
Weight About 250 g
Operating Temperature 0°C to +40°C
Operating Humidity 5% RH to 95% RH (non-condensing)
Power Adapter Input 100 V to 240 V AC, 50 Hz/60 Hz
System Power Supply 11 V to 14 V DC, 1.5 A
Static Power Consumption 5.3 W
Maximum Power Consumption 18 W
Ports 1POTS+4GE+2.4G/5G Wi-Fi+1USB
Optical Connector SC/APC SC/PC
Indicators Power/PON/LOS/LAN/TEL/WLAN/WPS
Power Consumption 12W
Order Info
Part Number Description
HG8145V5 GPON ONU, 4×GE + 1×POTS + 1×USB + 2.4G/5G Wi-Fi 5dBi, external DC 12V/1.5A power supply.
Production Facility
FAQ
Q1. What optical communication products are available?
A comprehensive range of fiber optic equipment is available, including FTTH ONU/OLT, SFP Modules, Fiber Media Converters, PoE Switches, and other related solutions.
Q2. How is product quality guaranteed?
Quality is strictly managed through the evaluation of pre-production samples prior to mass production, followed by a mandatory 100% final inspection before shipment.
Q3. What are the technical capabilities of the EG8145V5?
The EG8145V5 is a high-performance GPON/XPON ONT featuring 4 Gigabit Ethernet (GE) ports, 1 POTS (VoIP) port, 1 USB port, and dual-band Wi-Fi (2.4G/5G). It supports both SC/APC and SC/PC connectors.
Q4. What is the power consumption of this device?
The device operates with a highly efficient static power consumption of 5.3 W. Its maximum power consumption is rated at 18 W under full load conditions.
Q5. What delivery terms and payment options are supported?
  • Delivery Terms: FOB, CFR, CIF, EXW, DDP, Express Delivery, etc.
  • Payment Currencies: USD, EUR, CNY, and others.
  • Payment Methods: T/T, L/C, PayPal, Western Union, Credit Card, Escrow, etc.
Q6. Which languages are supported for communication?
Global client support is provided in multiple languages including English, Chinese, Spanish, French, Russian, and more.
