Point-to-multipoint high-speed forwarding
| Hardware Specifications | |
|---|---|
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface | • 1*155Mbps SC optical fiber interface • 4*RJ45 10/100Mbps |
| Distance | • 100m @CTE5 • 20km @SMF |
| Wavelength | • A:Tx1310nm/Rx1550nm • B:Tx1550nm/Rx1310nm |
| Transmission media | • Cable: CTE5 or higher UTP and STP • Optical Fiber: 9/125um single-mode optical fiber |
| Optical parameter | • Average emission power: -9 to -3 dBm • Receiving sensitivity: -22 dBm |
| Power | • DC5V/2A |
| Size | • 94.5mm*73mm*27mm |
| Environment | • Operating temperature: -5°C to 60°C • Operating humidity: 10% to 90% RH (non-condensing) • Storage temperature: -40°C to 70°C • Storage humidity: 5% to 90% RH (non-condensing) |
| Order Info | |
|---|---|
| RD-FE104-T | Fiber Media Converter 10/100MB 1*SC+4*RJ45 1310-TX |
| RD-FE104-R | Fiber Media Converter 10/100MB 1*SC+4*RJ45 1550-TX |
