Home > Standard Series > Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
1 / 5
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System
Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System

Durable 10/100Mbps Single Mode Fiber Media Converter 1 FX to 8 TX 20km SC for Large CCTV System

Send Inquiry

Product Description

Product Design
Product Design Banner
Product Detail 1
Product Detail 2
1 Fiber Port with 8*10/100Mbps RJ45 Port
Point-to-multipoint high-speed forwarding
Port Details
Plug-and-Play Configuration
Easy setup with no configuration required for instant operation.
Plug and Play Setup
Product Dimensions and Interface Definitions
Compact layout optimized for standard setups.
Dimensions and Interfaces
Application Scenario
Robust networking integration for various commercial and industrial settings.
Application Diagram
Specification
Parameter Details
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Interface
  • 1 * 155Mbps SC optical fiber interface
  • 8 * RJ45 10/100Mbps ports
Distance
  • 100m @ CTE5
  • 20km @ SMF
Wavelength
  • A: Tx1310nm / Rx1550nm
  • B: Tx1550nm / Rx1310nm
Transmission Media
  • Cable: CTE5 or higher UTP and STP
  • Optical Fiber: 9/125μm single-mode optical fiber
Optical Parameter
  • Average emission power: -9 to -3 dBm
  • Receiving sensitivity: -22 dBm
Power DC 5V / 2A
Size 195mm * 92mm * 28mm
Environment
  • Operating temperature: -5°C to 60°C
  • Operating humidity: 10% to 90% RH (non-condensing)
  • Storage temperature: -40°C to 70°C
  • Storage humidity: 5% to 90% RH (non-condensing)
Order Info
Model Description
RD-FE108-T Fiber Media Converter 10/100MB 1*SC + 8*RJ45 1310-TX
RD-FE108-R Fiber Media Converter 10/100MB 1*SC + 8*RJ45 1550-TX
This product is set by default to have a fiber transmission distance of 20 kilometers. However, you can also purchase it based on the actual distance required.
FAQ
1. Who are we?
We are a professional optical communication manufacturer founded in 2017. Our products are sold worldwide, with key markets including Asia, North America, Europe, the Middle East, and South America. We have a dedicated team serving global clients.
2. How do we guarantee quality?
We strictly follow standardized quality protocols:
  • Pre-production samples are thoroughly evaluated before starting mass production.
  • We perform a 100% final inspection on all units before shipment to ensure reliable performance.
3. What products can you purchase from us?
We offer a comprehensive range of fiber optic equipment, including FTTH ONU/OLT, SFP Modules, Fiber Media Converters, PoE Switches, and other optical communication solutions.
4. Why should you choose us?
As a top-tier optical communication supplier, we specialize in advanced PON and switching solutions. Supported by a strong engineering team and a professional workforce, we deliver highly reliable products and value-added services for partners worldwide.
5. What delivery and payment services do we provide?
We offer flexible transactional options:
  • Delivery Terms: FOB, CFR, CIF, EXW, DDP, Express Delivery, etc.
  • Payment Currencies: USD, EUR, CNY, and others.
  • Payment Methods: T/T, L/C, PayPal, Western Union, Credit Card, Escrow, etc.
  • Languages Spoken: English, Chinese, Spanish, French, Russian, etc.
6. Can the transmission distance be customized?
Yes. While the default configuration is set to a 20-kilometer fiber transmission distance, the hardware parameters can be customized based on your project requirements.
