| Specification parameters | |
|---|---|
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface | 1*155Mbps SC optical fiber interface 1*10/100Mbps adaptive RJ45 port |
| Wavelength | 1310nm |
| Distance | Maximum transmission distance: 3km |
| Optical parameter | Optical power: -17~-1dBm Reception sensitivity: -22dBm |
| Media | Cable: Category 5 or higher UTP and STP Fiber: 50/125um or 62.5/125um multimode optical fiber |
| Power | DC12V/1A |
| Size | 95mm*74mm*27mm |
| Operating environment | Working temperature: -20°C to 60°C Storage temperature: -40°C to 85°C Working humidity: 10% to 90% RH without condensation Storage humidity: 5% to 90% RH without condensation |
| Model Number | Optic Fiber | Wavelength | Distance |
|---|---|---|---|
| RD-FE102-M | Dual fiber Singlemode | 850nm | 550m |
| RD-FE102-A | SMF(1) | 1310nm/1550nm | 3km |
| RD-FE102-B | SMF | 1550nm/1310nm | 3km |
| RD-FE102-20A | SMF | 1310nm/1550nm | 20km |
| RD-FE102-20B | SMF | 1550nm/1310nm | 20km |
| RD-FE102-40A | SMF | 1310nm/1550nm | 40km |
| RD-FE102-40A | SMF | 1550nm/1310nm | 40km |
(1) SMF: Single fiber Singlemode.
(2) Distance options: 0-120km.
