Equipped with a high-speed and stable quality chip to ensure seamless network transmission.
No configuration is needed. Simply plug in the fiber optic network cable to start using it, saving significant maintenance resources.
Features a dual-sided ventilation cooling design, providing strong airflow to ensure stable operation over long periods.
Adopts high-quality chips optimized for high-speed stability, low power consumption, and minimal signal loss.
Easily monitor system status at a glance, allowing for quick diagnosing and troubleshooting of network connectivity.
| Parameter | Details |
|---|---|
| Standards | IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-TX/FX |
| Ethernet Port | Connector: RJ45 Data Rate: 10/100/1000M Distance: 100m UTP Type: UTP-5E or higher level |
| Fiber Port | Connector: SC/FC/ST/SFP slot Data Rate: 1.25Gbps Distance: 3km - 120km |
| Port Configurations | 1 RJ45 port, Single fiber port (SC/LC/ST/FC Optional) |
| Performance | Processing Type: Store and Forward MAC Table Size: 2K Buffer Space: 1Mbit Maximum packet length: 9K Back bandwidth: 4G Time Delay: < 20μs |
| Forward / Filter Rate | 10M: 14,880pps 100M: 148,800pps 1000M: 1,488,000pps |
| Power Supply | External: 5V DC 1A Built-in: 100 V to 240 V AC 50Hz to 60Hz Power Consumption: ≤ 5W |
| Operating Temp | 0 °C to +70 °C |
| Storage Temp | -20 °C to +80 °C |
| Relative Humidity | 5% to 90% (non-condensing) |
| Part Number | Optic Fiber | Wavelength | Distance |
|---|---|---|---|
| HTB-GS03 AB | Single mode | A: 1310nm-TX / 1550nm-RX B: 1550nm-TX / 1310nm-RX |
3km |
| HTB-GS03-20 AB | Single mode | A: 1310nm-TX / 1550nm-RX B: 1550nm-TX / 1310nm-RX |
20km |
| HTB-GS03-40 AB | Single mode | A: 1310nm-TX / 1550nm-RX B: 1550nm-TX / 1310nm-RX |
40km |
