1
1 fiber port with 8*10/100Mbps RJ45 port
Point-to-multipoint high-speed forwarding
2
Plug-and-play, no need for any configuration
3
Product dimensions and interface definitions
| Hardware Specifications |
| Standard |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface |
- 1*155Mbps SC optical fiber interface
- 8*RJ45 10/100Mbps
|
| Distance |
|
| Wavelength |
- A: Tx1310nm/Rx1550nm
- B: Tx1550nm/Rx1310nm
|
| Transmission media |
- Cable: CTE5 or higher UTP and STP
- Optical Fiber: 9/125um single-mode optical fiber
|
| Optical parameter |
- Average emission power: -9 to -3 dBm
- Receiving sensitivity: -22 dBm
|
| Power |
DC5V/2A |
| Size |
195mm*92mm*28mm |
| Environment |
- Operating temperature: -5℃ to 60℃
- Operating humidity: 10% to 90% RH (non-condensing)
- Storage temperature: -40℃ to 70℃
- Storage humidity: 5% to 90% RH (non-condensing)
|
| Order Info |
| RD-FE108-T |
Fiber Media Converter 10/100MB 1*SC+8*RJ45 1310-TX |
| RD-FE108-R |
Fiber Media Converter 10/100MB 1*SC+8*RJ45 1550-TX |
This product is set by default to have a fiber transmission distance of 20 kilometers. However, you can also purchase it based on the actual distance required.
Frequently Asked Questions
Q1: What is your MOQ request?
Depends on products, different products have different MOQ.
Q2: Do you Support ODM/OEM service?
Yes, we can offer the customization service to you.
Q3: Does your products support other brands?
Yes, all of our products is without lock, support to another brands too.
Q4: Are you the manufacturer or trading company?
We are the manufacturer, we support factory view tour.
Q5: Do you offer free samples?
Yes, for some models we are able to provide the free samples for your testing purpose.
Q6: Are you able to provide the local certificates?
Yes, according the contract agreement, we are able to apply for the local certificates for you, such as Postel/CE/Rohs/Anatel etc.
