| Hardware Specifications |
| Standard |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface |
- 1*1.25Gbps SC optical fiber interface
- 4*RJ45 10/100/1000Mbps
|
| Distance |
|
| Wavelength |
- A: Tx1310nm/Rx1550nm
- B: Tx1550nm/Rx1310nm
|
| Transmission media |
- Cable: CTE5 or higher UTP and STP
- Optical Fiber: 9/125um single-mode optical fiber
|
| Optical parameter |
- Average emission power: -9 to -3 dBm
- Receiving sensitivity: -22 dBm
|
| Power |
DC5V/2A |
| Size |
94mm*73mm*27mm |
| Environment |
- Operating temperature: -5°C to 60°C
- Operating humidity: 10% to 90% RH (non-condensing)
- Storage temperature: -40°C to 70°C
- Storage humidity: 5% to 90% RH (non-condensing)
|
| Order Info |
| RD-GE104-T |
Fiber Media Converter 10/100/1000MB 1*SC+4*RJ45 1310-TX |
| RD-GE104-R |
Fiber Media Converter 10/100/1000MB 1*SC+4*RJ45 1550-TX |
This product is set by default to have a fiber transmission distance of 20 kilometers. However, you can also purchase it based on the actual distance required.
FAQ
What is your MOQ request?
Depends on products, different products have different MOQ.
Do you Support ODM/OEM service?
Yes, we can offer the customization service to you.
Does your products support other brands?
Yes, all of our products is without lock, support to another brands too.
Are you the manufacturer or trading company?
We are the manufacturer.
Do you offer free samples?
Yes, for some models we are able to provide the free samples for your testing purpose.
Are you able to provide the local certificates?
Yes, according the contract agreement, we are able to apply for the local certificates for you, such as Postel/CE/Rohs/Anatel etc.
