G5600V2 is a highly integrated, medium-capacity box-type GPON OLT. It is designed to be widely used in operator FTTH access, private network access, government and enterprise park access, campus network access, and other access network construction scenarios.
| Attributes | Description |
|---|---|
| Interface | 2*GPON Port, 2*10/100/1000M Base-T; 2*1000M Base-X SFP / 2*10GE SFP+ |
| Exchange Capacity | 51.5Gbps |
| Forwarding Rate | 59.7Mpps |
| Memory & Flash | Memory: 32MB; Storage: 512MB |
| Management Port | Console, MGMT |
| PON Standard | Complies with ITU-T G.984/G.988 standards; 20 km physical differential distance; 1:128 maximum splitting ratio; Standard OMCI management. |
| Power Supply | AC: 100~240V 47/63Hz; DC: 12V |
| Power Consumption | ≤30W |
| Dimensions | 270mm * 44mm * 180mm |
| Environment | Working Temp: -10°C~55°C; Humidity: 5%~95% (non-condensing) |
| Model Number | Detailed Description |
|---|---|
| G5600V2 |
• 2*GPON port + 2GE RJ45 + 2*GE/10GE SFP+ uplink port • GPON PON Transceiver (Class C++) included • AC/DC optional dual power supply • EU & US power plug optional |
