100G Ethernet Data Center Fiber Optic Transceiver Module 4-Channel PSM4 500m MPO 1310nm QSFP28

Product Description

Product Presentation
Specification
Part No. QSFP-100G-PSM4 Vendor Name -
Form Factor QSFP28 Max. Data Rate 103.125Gbps (4x 25.78Gbps)
Wavelength 1310nm Max. Cable Distance 500m
Connector MTP/MPO-12 Media SMF
Transmitter Type 4x DFB Receiver Type PIN
TX Power -9.4~2dBm Receiver Sensitivity -12.66dBm
Power Budget 3.26dB Receiver Overload 2dBm
Power Consumption ≤3.5W Extinction Ratio >3.5dB
DDM/DOM Supported Warranty 2 Years
Commercial Temperature Range 0 to 70°C (32 to 158°F) Protocols QSFP28 MSA Compliant
Newly-Made, Quality Guaranteed
Newly-Made, Quality Guaranteed
Tested in Host Devices for Proven Interoperability
Tested in Host Devices for Proven Interoperability
Comprehensive Testing Increases Reliability
Comprehensive Testing Increases Reliability
Order Info
Model Introduction
QSFP28-100G-SR4 100G QSFP28 MMF 850nm 100m MPO DOM
QSFP28-100G-PSM4 100G QSFP28 SMF 1310nm 500m MPO DOM
QSFP28-100G-CWDM4 100G QSFP28 SMF 1310nm CWDM4 2km LC DOM
QSFP28-100G-LR4 100G QSFP28 SMF 1310nm 10km LC DOM
QSFP28-100G-ER4 100G QSFP28 SMF 1310nm 40km LC DOM
QSFP28-100G-ZR4 100G QSFP28 SMF 1310nm 80km LC DOM
FAQ
Q Can you do OEM?
Yes, we can do OEM products. It's no problem.
Q How is quality control managed?
Every single optic module is individually tested in our test center, and also tested for compatibility on a variety of different network equipments.
Q Can I get a sample first?
Yes, we can provide samples for you to check the quality.
Q How about the payment terms?
We accept T/T, western union, Alibaba order...
Q What is the lead time?
For usual order, we keep stock, could ship about 3 days after receiving the payment. For big quantity & special products, please check lead time with our sales.
Q How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
