| Model Number | HG7024XZ |
| Interface | 1* G/EPON + 4*GE + 2.4G/5.8G WLAN + 1*RF |
| Ethernet Interface | 4* RJ45 10/100/1000BASE-T |
| CATV Interface |
• Interface type: 1*RF • Optical receiving wavelength: 1550nm • RF output level: 80±1.5dBuV • Input optical power: +2 ~ -15dBm • AGC range: 0 ~ -12dBm • Optical reflection loss: >14 • MER: >31@-15dBm |
| PON Interface |
• Interface Type: SC/UPC, CLASS B+ • Transmission distance: 0 ~ 20km • Working wavelength: Up 1310nm / Down 1490nm • RX Optical power sensitivity: -27dBm • Transmission rate: - GPON: Up 1.244Gbps / Down 2.488Gbps - EPON: Up 1.244Gbps / Down 1.244Gbps |
| Wireless |
• Interface type: External 4*2T2R External antenna • Antenna gain: 5dBi • Interface maximum rate: - 2.4G WLAN: 300Mbps - 5.8G WLAN: 866Mbps • Interface working mode: - 2.4G WLAN: 802.11 b/g/n - 5.8G WLAN: 802.11 a/n/ac |
| Indicator light | RF / OPT / 5G / 2.4G / LAN4 / LAN3 / LAN2 / LAN1 / LOS / PON / POWER |
| Power Supply | DC 12V / 1.5A |
| Power Adapter Input | 100V-240V AC, 50Hz-60Hz |
| Power Consumption | 12W |
| Working Temperature | -20°C ~ +50°C |
| Environment Humidity | 5% ~ 95% (non-condensing) |
| Dimensions (L×W×H) | 196mm x 125mm x 32mm |
| Description | |
|---|---|
| XPON, 4*1000M Base-T, 1*WIFI-5 (2.4G & 5G 1200M), 1*CATV, 12V/1.5A. |
