| Item | ZXA10 C320 |
|---|---|
| Backplane capacity | 420 Gbit/s |
| Switching capacity | 84 Gbit/s |
| Number of service cards | 2 (GPON/P2P/XG-PON1) |
| Number of combined control cards | 2 |
| Number of power supply cards | 1 |
| Number of uplink cards | 1 (10GE/GE/FE/E1/T1) |
| Maximum number of GPON subscribers | 4096 |
| Management Interfaces | CLI, SSH, SNMP, telnet |
| Power | -48 V (DC), 230V (AC) |
| Working temperature and humidity | -25°C – +55°C, 5% – 95% |
| Split Ratio | up to 1:128 |
| Range | 20-60 km |
| Maximum attenuation | SFP B+ 28 dB, SFP C+ 32 dB |
| Dynamic Bandwidth Allocation | NSR-DBA, SR-DBA |
| Support | FEC, AES128, SCB, OLS |
| Dimensions | 86.1 mm (height) x 482.6 mm (width) x 270 mm (depth) |
| Power Supply | Dual DC: 48V/60VAC: 100V~240V |
| Cabinet | Indoor: 2200mm x 600mm x 300mm standard cabinet Outdoor: EC90EB, EC70E |
| Main-Control Switching Card SMXA | Panel interfaces: 1*10GE/GE(optical)+1*GE/FE(Optical)+ 1*GE/FE(electrical) 1*serial port+ 1*management FE+ 1*environment detecting port Ethernet uplink port: MAX. 2*10GE+4*GE or 6*GE |
| Service Card (2 slots) | GTGO(8*GPON) /GTGH(16*GPON)/FTGK(48*P2P)/GTXO(8*XG-PON1) |
| GPON | Port | XG-PON | XGS-PON | XG-PON and GPON Combo | XGS-PON and GPON Combo | |
|---|---|---|---|---|---|---|
| C300/C320/C350 | GTGO | 8 | GTXO | GTTO | GTBO | - |
| GTGH | 16 | - | - | - | - | |
| C600/C650/C680 | GFGH | 16 | GFXH | GFTH | GFBN/GFBH | GFCH |
