| Technical Specification | |
|---|---|
| Interface | 4GE+1USB+WIFI6+G/EPON |
| LED | POWER+PON/LOS +INTERNET +LAN + WiFi + WPS+USB |
| Flash & Memory | Flash: 256MB NAND; Memory: 512 DDR4 |
| Power Supply | 12V/1.5A |
| Power Consumption | ≤15W |
| Environment Standard | Operating Temperature: -5℃~45℃ Storage Temperature: -20℃~70℃ Relative Humidity: 5%~95% (non-condensing) |
| Weight | 0.35KG |
| Size W*D*H | 190mm*135mm*33mm |
| Module Type | Class B+, SC/UPC |
| Wavelength | UP 1310nm, Down 1490nm |
| TX Optical Power | 0.5~5dbm |
| RX Optical Sensitivity | -28dBm |
| Transmission Distance | 0~20km |
| Transmission Rate | EPON: Upstream 1.25Gbps/Downstream 1.25Gbps GPON: Upstream 1.25Gbps/Downstream 2.5Gbps |
| LAN Interface Type | RJ45 (10/100/1000Mbps) |
| USB | USB3.0 |
| WIFI | Dual-band WIFI6 AX3000 (2 ×2 MIMO (2.4G & 5G)) |
| Description |
|---|
| XPON, 4*1000M Base-T, 1*WIFI-6 (2.4G & 5.8G 3000M), 1*USB3.0, 12V/1.5A |
| XPON, 4*1000M Base-T, 1*POTS, 1*WIFI-6 (2.4G & 5.8G 3000M), 1*USB3.0, 12V/1.5A |
| XPON, 4*1000M Base-T, 1*POTS, 1*WIFI-6 (2.4G & 5.8G 3000M), 1*USB3.0, 1*CATV, 12V/1.5A |
