The POE Splitter is designed based on the IEEE 802.3af/at standard, acting as standard POE remote electric equipment. It separates power and data signals transmitted via network cables. It is fully compatible with standard power supply equipment (PSE) and enables non-PoE network devices to receive both data and power concurrently.
Support IEEE 802.3af/at Power over Ethernet standard.
Support 10/100Mbps data transmission rates.
PoE Splitter receiving end supports a wide voltage range of 40V-57V transfer.
Provide stable 12V 1.2A power output to adapt to various small network devices.
Circuit isolation protection design, effectively securing the connected electrical equipment.
High-quality industrial design guarantees long-term stability and reliability under workload.
| Product Model | PS4812-O | PS4812G-O |
|---|---|---|
| POE Voltage | 40V-57V | |
| Output Voltage | 12V | |
| Output Current | 1.2A | 2A |
| Power Supply Mode | 1/2(+)/3/6(-) | 1/2(+)/3/6(-) |
| Agreement | IEEE802.3-AF/IEEE802.3-AT | |
| Transmission Rate | 10/100Mbps | 10/100/1000Mbps |
| Transmission Distance | 100 meters | |
| Wire Type | Class 5 and over class 5 unshielded twisted pair | |
| Waterproof | Yes | |
| Working Temperature | -20℃ to 60℃ | |
| Working Humidity | 0-90% (No condensation) | |
| Model | Introduction |
|---|---|
| PS4812 | 10/100M PoE splitter 48V to 12V/1.2A IEEE802.3af Isolated type: 1.5KV |
| PS4812G | 10/100/1000M PoE splitter, 48V to 12V/2A, IEEE802.3af, Isolated type: 1.5KV |
| PS4812W | White Waterproof 10/100M PoE splitter, 48V to 12V/1A, IEEE802.3af |
| PS4812-O | Outdoor 10/100M PoE splitter, 48V to 12V/1.2A, IEEE802.3af, Isolated type: 1.5KV |
| PS4812G-O | Outdoor 10/100/1000M PoE splitter, 48V to 12V/2A, IEEE802.3af, Isolated type: 1.5KV |
