Product Description

10/100Mbps Optical Fiber Transceiver

High speed and stable quality chip

High Quality is Trustworthy

We pursue excellence, quality is still, live up to ten thousand praise

Product Information

Detailed technical drawings and product dimension layout

Super Heat Dissipation, Long Service Life

There are vents on both sides, which can provide better heat dissipation and ensure the normal high-speed operation of the machine

Data Transmission of Imported Chip is Stable

Main control chip, realize data fast forwarding single fiber two-way transceiver body module, strong anti-interference ability, high speed and stable performance

Suitable for a Wide Range of Purposes

Can adapt to a variety of working environments: community networks, campus enterprise networks, fiber to the home, intelligent broadband, monitoring, security, and other fields

Specifications

Part Number	HTB-3100AB
Standards	IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX
Ethernet Port	Connector: RJ45 Data Rate: 10/100Mbps Distance: 100m UTP Type: UTP-5E or higher level
Fiber Port	Connector: SC port Data Rate: 10/100Mbps Distance: 25km
Port	1RJ45 port, 1 fiber port (SC/LC/ST/FC Optional)
Forward / Filter Rate	10M: 14,880/14,880pps 100M: 148,800/148,800pps
Power Supply	External : 5V DC 1A Built-in: 100 V to 240 V AC 50Hz to 60Hz Power Consumption : ≤5W
Operating Temperature	0 °C to +70 °C
Storage Temperature	-20 °C to +80 °C
Relative Humidity	5% to 90% (non-condensing)
Warranty	1 Year

Order Information

Model	Introduction	Function
HTB-3100AB	Fiber Media Converter 10/100Mbps 25km	Fiber Media Converter, 10/100Mbps 1Simplex SC -1LAN SM 25km SC DC5V power supply, A:Tx1310nm/Rx1550nm Fiber Media Converter, 10/100Mbps 1Simplex SC -1LAN SM 25km SC DC5V power supply, B:Tx1550nm/Rx1310nm
HTB-GS03AB	Fiber Media Converter 10/100/1000Mbps 3km	Fiber Media Converter, 10/100/1000Mbps 1Simplex SC -1LAN SM 3km SC DC5V power supply, A:Tx1310nm/Rx1550nm Fiber Media Converter, 10/100/1000Mbps 1Simplex SC -1LAN SM 3km SC DC5V power supply, B:Tx1550nm/Rx1310nm
HTB-GS03-20AB	Fiber Media Converter 10/100/1000Mbps 20km	Fiber Media Converter, 10/100/1000Mbps 1Simplex SC -1LAN SM 20km SC DC5V power supply, A:Tx1310nm/Rx1550nm Fiber Media Converter, 10/100/1000Mbps 1Simplex SC -1LAN SM 20km SC DC5V power supply, B:Tx1550nm/Rx1310nm

Frequently Asked Questions

QWho are we?

We are an optical communication manufacturer founded in 2017. Our products are sold worldwide, with key markets including Asia, North America, Europe, the Middle East, and South America.

QHow do we guarantee quality?

We guarantee quality by providing pre-production samples before mass production and conducting a 100% final inspection before shipment.

QWhat products can you buy from us?

We offer a wide range of optical products including FTTH ONU/OLT, SFP Modules, Fiber Media Converters, PoE Switches, and other optical equipment.

QWhy choose our optical communication solutions?

We are a top-tier optical communication supplier. Our core focus is on PON and switching solutions, supported by a strong engineering team to deliver reliable products and value-added service for partners worldwide.

QWhat services and transaction terms do we provide?

We support diverse delivery terms (FOB, CFR, CIF, EXW, DDP, Express Delivery, etc.), multiple payment currencies (USD, EUR, CNY, etc.), secure payment methods (T/T, L/C, PayPal, Western Union, Credit Card, Escrow, etc.), and multi-language support.

QWhat is the transmission distance and warranty of the HTB-3100AB?

The HTB-3100AB Fiber Media Converter supports a transmission distance of up to 25km and is backed by a 1-year product warranty.
